• Battery charger system with I/U charging characteristics
  • Micro controller-based battery management
  • Temperature compensation for charging voltage by means of external sensor module (optional module)
  • USB interface with appropriate driver unit and TECControl Software of J. Schneider, message contacts may
    be controlled and a shut down/re-start can be effected
Art.-no. : NBPA0616G01005

Technical Data

Input voltage 115 ... 230 V AC
Frequency 47 ... 63 Hz
Nominal output voltage / Nominal output current 48 V DC / 2,5 A
Dimensions (H x W x D) 160 mm x 75 mm x 150 mm
Weight ca. 1,0 kg
