NBBH 24100

Battery module 24 V, 100 Ah


  • Lifetime according to Eurobat up to 5 years

  • Accumulator sealed
  • maintenance-free
  • installation position any
Art.-no. : NBBH0336G01010

Technical data

nominal voltage 24 V
capacity 100 Ah
dimensions (H x W x D) 2*(170 x 397 x 200 mm)
weight 2 x 31 kg

Product features

  • mounting orientation free available (not standing on top)
  • impact resistant and break-proof plastic housing made of ABS
  • VdS/UL-approval
  • plug valve controlled construction, nearly 100% oxygen recombination at each charging process
  • Electrolyte is bound in glass fiber mat or in gel
  • refilling of electrolyte is not necessary
  • non-corroding high power grid plates with lead-calcium corrosion
  • wide operational temperature range at corresponding voltage compensation depending on temperature
  • excellent charging efficiency
  • no dangerous good according to IATA
  • conformity to EN 61056-2
  • long life duration at low self discharge, 3% each month at 20°C
  • required air flow capacity Q according to EN 50272-2, part 8.2 at charging with IU- or U-charging characteristics
